Celestron CGX Equatorial 11" (1100) SCT Telescope

£5,224.00✓ 2 year warranty

:

Out of stock due 20-25 working days
Share

About this product

Model:  cel_cgx_1100_sct_12052
Part Number:  12052-CGL

The CGX 1100 Schmidt-Cassegrain Telescope features Celestron’s premium StarBright XLT coated optics and the all-new state of the art CGX computerised equatorial mount.

The 11" optical tube assembly weighs 27.5 lb so this telescope is still portable enough to be taken to dark skies, and delivers 89% more light gathering power than an 8" telescope and more than 40% more than the 9.25".

For eight years, Celestron’s workhorse CGEM mount lineup has been the German Equatorial backbone for telescopes ranging from 6 to 11 inches of aperture. Since that time, many more astro-imagers and planetarium controlled setups have emerged as backyard telescope technology has evolved. Celestron’s engineering team applied their years of experience designing German Equatorial mounts to the all-new CGX EQ, a culmination of all the advancements made to Celestron’s technologies, value, and ease-of-use.

The new CGX was designed to support your telescope for both visual and astro-imaging pursuits.  Key design goals included a lower profile EQ head for a more compact and therefore more stable setup; a better drive system; remote operation-friendly with home and limit optical sensors; easier polar alignment adjustments and better cable management. In addition, there are several mechanical and ergonomic improvements to make the mount sturdier, easier to use and transport.

CGX Intro Video




GENERAL FEATURES

  • 11" Schmidt-Cassegrain Optical Tube Assembly
  • Aluminum Optical Tube
  • Celestron's premium StarBright XLT coatings
  • 2800 mm focal length (f/10)
  • 40 mm eyepiece included (70x)
  • Visual back allows for use with 1.25" accessories 9x50 finderscope to help accurately find objects
  • Star diagonal provides more comfortable viewing position when observing objects that are high in the sky
  • Includes dovetail rail compatible with CGE mount

CGX MOUNT FEATURES

  • All-new design. Sturdier and more rigid with quicker dampening time
  • Increased load capacity to 55 lbs.
  • Improved motors provide more torque, better slewing and tracking under heavy loads
  • Heavy Duty belt-drive system minimises backlash while providing smooth motor operation under heavy loads
  • Spring-loaded brass worm wheel and stainless steel worm gear reduce friction and provide optimum gear mesh
  • Internal cabling for worry-free remote operation. Power input and accessory ports remain stationary while the mount slews to avoid snags
  • Internal hard stops for both axes prevents cable tension and tripod strike
  • Internal optical sensors on both axes for simple and safe remote operation
  • Home sensors allow the mount to always start in the index position regardless of orientation before a power reset
  • Limit sensors automatically shut off slewing or tracking before reaching the hard stop fail safe
  • Brand new control software developed in conjunction with PlaneWave Instruments for professional level control operation and imaging
  • Software includes multi-point mount modeling for extremely precise pointing accuracy and many more additional features for remote astroimaging
  • Wider tripod stance for improved stability
  • Adjustable EQ head position to optimize center of gravity over the tripod and fully utilize the increased 3º-65º latitude range
  • Dual-fit CG-5/Vixen and CGE/Losmandy dovetail saddle

IMPROVED TRIPOD FEATURES

  • 2" steel legs with height index marks for quick leveling
  • "Jack of all trays" can hold three 1.25" eyepieces, two 2" eyepieces, your smartphone, or other accessories
  • +20º of additional tracking past the meridian on either side
  • Tripod legs can be collapsed with accessory tray installed for faster setup and transport

CGX MOUNT ERGONOMICS

  • All-new ergonomically designed dovetail clamping knobs
  • Innovative and improved polar alignment adjustment system
  • All-new ergonomic latitude adjuster for smooth and easy adjustment under full loads
  • Optional add-on polar axis finderscope - coming soon

CGX MOUNT ELECTRONICS

  • All-new NexStar+ hand control with USB port
  • Two AUX accessory ports to support wireless/WiFi alignment and operation with StarSense AutoAlign and SkyPortal WiFi Module accessories (sold separately)
  • USB 2.0 port, used to connect directly to PC with included software
  • Autoguider port
  • PPEC ready
  • Threaded 12VDC power input barrel connector
  • Internal Real Time Clock (keeps time and site information saved)

What's in the box

  • Telescope OTA
  • 9x50 Finderscope
  • 1.25" Star Diagonal
  • 40mm Eyepiece
  • CGX Equatorial Head
  • CGX Tripod
  • Accessory Tray
  • 3x 5kg / 11lbs Counterweight
  • NexStar+ Hand Control
  • DC Power Cable (Cigar Plug)

Specifications

Optical DesignSchmidt-Cassegrain
Aperture (mm)279.4 mm (11 in)
Focal Length2800 mm (110 in)
Focal Ratio10
Focal Length of Eyepiece 1 (mm)40 mm (1.57 in)
Magnification of Eyepiece 170x
Finderscope9x50
Star Diagonal1.25
Optical TubeAluminum
Highest Useful Magnification660x
Lowest Useful Magnification40x
Limiting Stellar Magnitude14.7
Resolution (Rayleigh)0.5 arc seconds
Resolution (Dawes)0.42 arc seconds
Light Gathering Power (Compared to human eye)1593x
Secondary Mirror Obstruction3.75 in (95 mm)
Secondary Mirror Obstruction by Diameter34%
Secondary Mirror Obstruction by Diameter12%
Optical CoatingsStarBright XLT
Optical Tube Length24 in (610 mm)
Optical Tube Weight27.5lbs (12 kg)
Dovetail CompatibilityCGE Mount
MountGerman Equatorial
Instrument load capacity55lbs
Tripod height adjustment range47.25” to 77.5” including EQ head
Tripod leg diameter2"
Latitude adjustment range3º-65º
Tripod Weight19.2 lbs
EQ Head Weight44 lbs
Max Slew Speed5º/second (4º/second is default)
Tracking RatesSidereal, Solar and Lunar
Number of Auxiliary ports (for hand control and accessories)2
Autoguide portYes
USB PortYes
SoftwareNew telescope control PC software
